[vc_row][vc_column][vc_tta_tabs style=”flat” shape=”round” spacing=”15″ gap=”15″ alignment=”center” active_section=”1″ no_fill_content_area=”true”][vc_tta_section title=”Printers” tab_id=”printers”][vc_custom_heading text=”HYDRA 16A — The Rugged, Very Large Volume Printer for Serious Applications” font_container=”tag:h5|text_align:left” use_theme_fonts=”yes”][vc_row_inner][vc_column_inner width=”1/4″][vc_single_image image=”24982″ img_size=”full”][/vc_column_inner][vc_column_inner width=”1/4″][vc_column_text]SPECIFICATIONS IN X, Y, Z :[/vc_column_text][gem_list type=”checkbox” color=”3″]

  • 16A-S (Standard): 250mm Z (10″)
    • 400x300mm X/Y (16×12″) — 120°C or 200°C bed
    • 600x400mm X/Y (24×16″) — 120°C or 200°C bed
  • 16A-T: (Tall) 500mm Z (20″)
    • 600x400mm X/Y (24×16″) — 120°C or 200°C bed

[/gem_list][/vc_column_inner][vc_column_inner width=”1/4″][vc_column_text]SPECIFICATIONS IN X, Y, Z :[/vc_column_text][gem_list type=”checkbox” color=”3″]

  • 6x6x1 micron positional resolution
  • 60x60x10 micron positional accuracy
  • 30x30x5 micron positional repeatibility
  • Belt X/Y and Ballscrew Z positioning
  • Closed-loop encoder feedback motion
  • Proprietary motion control
  • Recommend print speeds up to 3000mm/min

[/gem_list][/vc_column_inner][vc_column_inner width=”1/4″][vc_column_text]SPECIFICATIONS IN X, Y, Z :[/vc_column_text][gem_list type=”checkbox” color=”3″]

  • Very Large scale prints
  • Multiple material prints
  • Multiple operations
  • Volume production
  • Circuit board milling, drilling, lasing
  • Options:
    • 40w CO2 laser
    • Three-phase spindle tool
    • Second Yoke (five more tool positions)

[/gem_list][/vc_column_inner][/vc_row_inner][gem_divider style=”7″ color=”#dfe5e8″][gem_divider style=”7″ color=”#dfe5e8″][vc_custom_heading text=”System 30M – The Workhorse for Material Science” font_container=”tag:h5|text_align:left” use_theme_fonts=”yes”][vc_row_inner][vc_column_inner width=”1/3″][vc_single_image image=”24983″ img_size=”full”][/vc_column_inner][vc_column_inner width=”1/3″][vc_column_text]SPECIFICATIONS IN X, Y, Z :[/vc_column_text][gem_list type=”checkbox” color=”3″]

  • 200x200x200mm (8x8x8″)
  • 5x5x1 micron positional resolution
  • 50x50x10 micron positional accuracy
  • 25x25x5 micron positional repeatibility
  • Belt-Belt-Ballscrew positioning
  • Proprietary motion control
  • Recommended print speeds up to 2000 mm/min

[/gem_list][/vc_column_inner][vc_column_inner width=”1/3″][vc_column_text]IDEAL FOR :[/vc_column_text][gem_list type=”checkbox” color=”3″]

  • Standard prints
  • Multiple material prints
  • Exotic materials
  • Experimentation

[/gem_list][/vc_column_inner][/vc_row_inner][gem_divider style=”7″ color=”#dfe5e8″][gem_divider style=”7″ color=”#dfe5e8″][vc_custom_heading text=”Engine SR – The Standard Resolution Platform for the Laboratory” font_container=”tag:h5|text_align:left” use_theme_fonts=”yes”][vc_row_inner][vc_column_inner width=”1/3″][vc_single_image image=”24981″ img_size=”full”][/vc_column_inner][vc_column_inner width=”1/3″][vc_column_text]SPECIFICATIONS IN X, Y, Z :[/vc_column_text][gem_list type=”checkbox” color=”3″]

  • 200x200x200mm (8x8x8″)
  • 5x5x1 micron positional resolution
  • 50x50x10 micron positional accuracy
  • 25x25x5 micron positional repeatibility
  • Belt-Belt-Ballscrew positioning
  • Proprietary motion control
  • Recommended print speeds up to 2000 mm/min

[/gem_list][/vc_column_inner][vc_column_inner width=”1/3″][vc_column_text]IDEAL FOR :[/vc_column_text][gem_list type=”checkbox” color=”3″]

  • Standard prints
  • Multiple material prints
  • Exotic materials
  • Experimentation

[/gem_list][/vc_column_inner][/vc_row_inner][gem_divider style=”7″ color=”#dfe5e8″][gem_divider style=”7″ color=”#dfe5e8″][vc_custom_heading text=”Engine HR – The High Resolution Platform for Biologicals and Micro-Scaffolds” font_container=”tag:h5|text_align:left” use_theme_fonts=”yes”][vc_row_inner][vc_column_inner width=”1/3″][vc_single_image image=”24980″ img_size=”full”][/vc_column_inner][vc_column_inner width=”1/3″][vc_column_text]SPECIFICATIONS IN X, Y, Z :[/vc_column_text][gem_list type=”checkbox” color=”3″]

  • 100x100x100mm (8x8x8″)
  • 1x1x1 micron positional resolution
  • 10x10x10 micron positional accuracy
  • 5x5x5 micron positional repeatibility
  • Ballscrew-Ballscrew-Ballscrew positioning
  • Proprietary motion control
  • Recommended print speeds up to 1000 mm/min

[/gem_list][/vc_column_inner][vc_column_inner width=”1/3″][vc_column_text]IDEAL FOR :[/vc_column_text][gem_list type=”checkbox” color=”3″]

  • Small scale prints
  • Biologels
  • Crosslinking resins
  • Microscaffolding
  • Tissue engineering

[/gem_list][/vc_column_inner][/vc_row_inner][gem_divider style=”7″ color=”#dfe5e8″][gem_divider style=”7″ color=”#dfe5e8″][/vc_tta_section][vc_tta_section title=”Modular Heads” tab_id=”modular-heads”][vc_column_text]

Modular Heads

HOT FLOW HEADS
FOR 1.75MM FILAMENTS AT UP TO 450°C

STANDARD

MK1250

MK1-250
EXTRUDER

Standard Hot Flow
For the most common 1.75mm filaments on the market with service temperatures up to 250°C.
ABS, Nylons, PLA, PETT, etc.
READ MORE

VERY HOT

MK1450

MK1-450
EXTRUDER

Very Hot Flow
For Exotic 1.75mm filaments with service temperatures between 250-450°C. Polycarbonate, PEEK, Ultem, Carbon Fiber
READ MORE

FLEXIBLE

MK2250

MK2-250
EXTRUDER

Flexible Hot Flow
For Flexible 1.75mm filaments with service temperatures up to 250°C.
BendLay, FilaFlex, NinjaFlex, etc.
READ MORE

COLD AND WARM FLOW HEADS
FOR CLAYS, PASTES, RESINS, ADHESIVES AND HIGH VISCOSITY EMULSIFIABLES

COLD

WARM

VERY WARM

emo25
vol-25
kra-15

EMO-25
EXTRUDER

Cold Flow
Compatible with Sugru (Rubber), Clay, Porcelain, Plasticine, Silicone RTV, PMC, stc.
READ MORE

VOL-25
EXTRUDER

Warm Flow
For emulsifiable materials with service temperatures up to 100°C, such as waxes and glues
READ MORE

KRA-15
EXTRUDER

Very Warm Flow
For emulsifiable materials with service temperatures up to 150°C.
READ MORE

Crosslinking options
All of our clay/emulsion/liquid/resin-type heads have UV Crosslinking On Deman (COD) options,
including a
COD UV LED array around the nozzle, and the newer UV Light Pen in 365, 405, and 450nm.

COLD FLOW SYRINGE HEADS
FOR LIQUIDS, GELS, BIOLOGICALS, AND OTHER LOW VISCOSITY EMULSIFIABLES

STANDARD

Hyrel_SDS-5_Left_SyringeRemoved

SDS-5
EXTRUDER

Sterile, Disposable
For low viscosity, room temperature materials with 5cc syringes. Liquids, Gels, Biologicals, etc.
READ MORE

STANDARD

Hyrel_SDS-10_Left_SyringeRemoved

SDS-10
EXTRUDER

Sterile, Disposable
For low viscosity, room temperature materials with 10cc syringes. Liquids, Gels, Biologicals, etc.
READ MORE

SPECIALITY

dsd

DSD
EXTRUDER

Dual Dispensing
For two-part mixtures at a 1:1 flow rate. Two-part epoxies.
Details soon!

Hyrel_SDS-30_Left_SyringeRemoved
Hyrel_SDS-60_Left_SyringeRemoved
SMH2

SDS-30
EXTRUDER

Sterile, Disposable
For low viscosity, room temperature materials with 30cc syringes. Liquids, Gels, Biologicals, etc.
READ MORE

SDS-60
EXTRUDER

Sterile, Disposable
For low viscosity, room temperature materials with 60cc syringes. Liquids, Gels, Biologicals, etc.
READ MORE

SMH-2
EXTRUDER

Static Mixing Head Assembly
For two-part mixtures at a variable, user-programmed flow rates, with static (fixed) blending baffles. These heads are in production and in use in the field today.

Specialty / other

Hyrel_QuietStorm_Right

QUIET STORM
COOLING FAN

Additional, Directed Cooling
Programmable cooling where you want it.
Position, Program, Peace of Mind
READ MORE

Hyrel_ST1_Right (1)

ST1
ROUTER

Engrave, Cut, Route
For simple operations only possible with a spindle tool. NOTE: you must supply your own fixturing. Paper, Wood, Metals (Drilling only), PCB (Routing), Acrylic
READ MORE

rsz_product-shark-5

LA6-450
LASER

Engrave, Cut, Trace
Add a 6 watt laser at 450 nanometers.
Cardboard, Foam, Paper, Acrylic, Metals (Engraving Only), PCB (Traces only)
READ MORE

microscope

INSPECTOR
MICROSCOPE

Illuminated, 100x  Magnification
For close inspection of output from any heads.
Position, Focus, Inspect
READ MORE

[/vc_column_text][vc_row_inner disable_element=”yes”][vc_column_inner width=”1/3″][gem_textbox content_background_color=”#46485c” top_style=”note-1″ centered=”1″ padding_top=”30″][vc_single_image image=”25029″ img_size=”full” alignment=”center”][vc_custom_heading text=”MK1-250 EXTRUDER” font_container=”tag:h5|text_align:center|color:%23ffffff”][gem_divider margin_top=”33″][vc_column_text css=”.vc_custom_1549189059776{padding-right: 15px !important;padding-left: 15px !important;}”]

Standard Hot Flow

For the most common 1.75mm filaments on the market with service temperatures up to 250°C.
ABS, Nylons, PLA, PETT, etc.

[/vc_column_text][gem_divider margin_top=”29″][/gem_textbox][/vc_column_inner][vc_column_inner width=”1/3″][gem_textbox content_background_color=”#46485c” top_style=”note-1″ centered=”1″ padding_top=”30″][vc_single_image image=”25044″ img_size=”full” alignment=”center”][vc_custom_heading text=”MK1-450 EXTRUDER” font_container=”tag:h5|text_align:center|color:%23ffffff”][gem_divider margin_top=”33″][vc_column_text css=”.vc_custom_1549206523865{padding-right: 15px !important;padding-left: 15px !important;}”]

Very Hot Flow

For Exotic 1.75mm filaments with service temperatures between 250-450°C. Polycarbonate, PEEK, Ultem, Carbon Fiber

[/vc_column_text][gem_divider margin_top=”29″][/gem_textbox][/vc_column_inner][vc_column_inner width=”1/3″][gem_textbox content_background_color=”#46485c” top_style=”note-1″ centered=”1″ padding_top=”30″][vc_single_image image=”25045″ img_size=”full” alignment=”center”][vc_custom_heading text=”MK2-250 EXTRUDER” font_container=”tag:h5|text_align:center|color:%23ffffff”][gem_divider margin_top=”33″][vc_column_text css=”.vc_custom_1549206666143{padding-right: 15px !important;padding-left: 15px !important;}”]

Flexible Hot Flow

For Flexible 1.75mm filaments with service temperatures up to 250°C.
BendLay, FilaFlex, NinjaFlex,
etc.

[/vc_column_text][gem_divider margin_top=”29″][/gem_textbox][/vc_column_inner][/vc_row_inner][/vc_tta_section][vc_tta_section title=”Materials” tab_id=”materials”][vc_column_text]

Materials

Click Image to View MSPS Sheet with Print Specifications for that Material.

HIPS

HIPS

NinjaFlex

Ninjaflex

T-Glase

Tglase

PVA

PVA

BendLay_vase

BendLay

Laybrick

Laybrick

PET

PET

ABS-PC_vase

ABS-PC Alloy

PETG_vase

PETG

Conductive_vase

Conductive ABS

PLA

PLA

ABS

ABS

Flex-PLA_vase

Flex EcoPLA

Nylon_vase

Nylon

Some materials we print with:

  • ABS (Acrylonitrile Butadiene Styrene)
  • BendLay
  • Clay
  • LayBrick
  • LayWood
  • Metal Clay
  • Ninjaflex
  • Nylon (Including Taulman 618, 645, 910)
  • PET (PolyEthylene Terephthalate)
  • PETG (PolyEthylene Terephthalate Glycol-modified)
  • PLA (Poly(Lactic Acid))
  • Plasticine
  • PlastInk Rubber
  • Play-Doh
  • PC (PolyCarbonate)
  • PP (PolyPropylene)
  • Porcelain
  • PVA (Poly(Vinyl Alcohol))
  • RTV Silicone
  • Sculpey
  • T-Glase
